Tubular Heating Elements

Tubular Heating is a type of heaters that can be used for different purposes. Tubular heating performs at quite high temperatures. We can use these products in all fields of our lives. Resistors, despite being a simple and practical product, play a vital role in many industrial fields due to the functions they perform.

In Which Areas Is Tubular Heating Used?

Many industries use tubular heating models, including plastics, packaging, woodworking, construction, and casting. It also finds a place for itself in high vacuum technologies and laboratory equipment. Besides, they are most used in electronic home appliances.

All the resistors produced by our company save energy. Also, they are reliable and affordable products. Many liquids such as corrosive liquids, oil and water can be heated by tubular heating. It can also be used for heating different substances or in different industrial areas.

Tubular Heating Technical Specifications

• Tubular heating is used for heating water, oil, chemical and corrosive liquids. It is also suitable for furnace molds and the heating of various metals.

• Diameters of tubular heating can be produced specially. They are produced as 6.5 mm, 8.5 mm, 11.5 mm, 14.5 mm, and 16 mm. Also, we can produce in any size between 5 mm and 20 mm.

• Tubular heating can operate with high performance up to 650 degrees.

• In these resistances, 304-321-316 – 310 S stainless steel materials can be used. We also use stainless tubes such as Alloy 800 – Alloy 825 and Alloy 600.

• We also manufacture coupling and flange connection resistances according to your preference.

• Apart from tubular shape, we can also produce U, M, and flat bar type resistors.

• Has an operating voltage of up to 400 V

• It has a power density of up to 10 W/cm².

How To Select a Tubular Heating?

Tubular Heating converts electrical energy into heat. In this way, heat is released in a very short time. Resistors are divided into different types according to their properties. Tubular heating is one of the most widely used products.

While choosing the resistance, you also need to evaluate in the way of quality and price. You can select according to the experience of the company and how long it has been working. You can contact our company now to order special tubular heating for all your needs.

Tubular Heating Prices

You can get a price offer by calling our company for tubular heating prices. These products are produced with different costs depending on the size and the material used. Also, the power and the highest temperature value of the product are effective on prices. Contact our company now to order tubular heating of all sizes and models.

We produce the type of resistance that will satisfy the needs you have as soon as possible. Contact us now through our communication information to order these long-lasting heating and to ask your questions.

Tube Heaters

Tube heaters are heating elements that convert electrical energy into thermal energy and are commonly used in industrial heating systems. These are typically heating elements placed inside metal tubes. The resistance elements, which are usually in the form of wires or bands, heat up with an electric current and heat the surrounding environment of the tube. This is utilized in industrial ovens, hot water tanks, steam generation, and many other heating applications. Tube resistors come in various sizes and power ratings and can often be customized to fit the specific requirements of an application.

Advantages of Tube Heaters

• Easy Installation: Tube resistors can be easily mounted and utilized.
• Efficiency: Tube resistors have a high heat transfer rate and use energy efficiently.
• Reliability: Tube resistors are long-lasting and durable.
• Versatility: Tube resistors can be used in various temperatures and environments.
• Cost-effectiveness: Tube resistors are more affordable compared to other heating methods.

Other advantages:

• Wide range of applications: Tube resistors can be used in industrial and commercial applications, household appliances, and laboratories.
• Adjustability: Tube resistors can be used with different temperature control options.
• Compactness: Tube resistors take up little space and are portable.
• Easy maintenance: Tube resistors can be easily cleaned and maintained.

Materials Used in Tube Heaters

• Heating Element:
  • Nickel-chromium (NiCr): The most commonly used heating element material. It is resistant to high temperatures and has a long lifespan.
  • Kanthal: Similar to nickel-chromium alloy. It is more resistant to higher temperatures and corrosion.
  • Fe-Cr-Al: A material used at lower temperatures. It is cheaper and easier to process.
• Body Material:
  • Stainless steel: The most commonly used body material. It is resistant to corrosion and has a long lifespan.
  • Copper: It has high heat conductivity and provides fast heating.
  • Brass: A cheaper material that is easier to work with.
• Insulation Material:
  • Magnesium oxide: The most commonly used insulation material. It is resistant to high temperatures and is a good electrical insulator.
  • Ceramic: It is resistant to higher temperatures and provides better insulation.
  • Silicone: A more flexible material that is resistant to vibration.
• Other Used Materials:
  • Gam: A material used in special applications.
  • Quartz: It is resistant to high temperatures and corrosion.
  • Titanium: It is resistant to very high temperatures and corrosion.
